ZyAIR G-2000 Plus User’s Guide
Chapter 31 SNMP Configuration 330
Figure 183 Menu 22 SNMP Configuration
Menu 22 - SNMP Configuration
SNMP:
Get Community= public
Set Community= public
Trusted Host= 0.0.0.0
Trap:
Community= public
Destination= 0.0.0.0
Press ENTER to Confirm or ESC to Cancel:
The following table describes the SNMP configuration parameters.
Table 110 Menu 22 SNMP Configuration
FIELD DESCRIPTION
SNMP:
Get Community Type the Get Community, which is the password for the incoming Get- and
GetNext requests from the management station.
Set Community Type the Set Community, which is the password for incoming Set requests from
the management station.
Trusted Host If you enter a trusted host, your ZyAIR will only respond to SNMP messages from
this address. A blank (default) field means your ZyAIR will respond to all SNMP
messages it receives, regardless of source.
Trap:
Community Type the trap community, which is the password sent with each trap to the SNMP
manager.
Destination Type the IP address of the station to send your SNMP traps to.
When you have completed this menu, press [ENTER] at the prompt “Press ENTER to confirm or ESC
to cancel” to save your configuration or press [ESC] to cancel and go back to the previous screen.
31.4 SNMP Traps
The ZyAIR will send traps to the SNMP manager when any one of the following events
occurs:
Table 111 SNMP Traps
TRAP # TRAP NAME DESCRIPTION
1 coldStart (defined in RFC-1215) A trap is sent after booting (power on).
2 warmStart (defined in RFC-1215) A trap is sent after booting (software reboot).
3 linkUp (defined in RFC-1215) A trap is sent when the port is up.
