ZyAIR G-2000 Plus User’s Guide
313 Chapter 29 Filter Configuration
29.1.1 The Filter Structure of the ZyAIR
A filter set consists of one or more filter rules. Usually, you would group related rules, e.g., all
the rules for NetBIOS, into a single set and give it a descriptive name. The ZyAIR allows you
to configure up to twelve filter sets with six rules in each set, for a total of 72 filter rules in the
system. You
cannot mix device filter rules and protocol filter rules within the same set. You
can apply up to four filter sets to a particular port to block multiple types of packets. With each
filter set having up to six rules, you can have a maximum of 24 rules active for a single port.
Sets of factory default filter rules have been configured in menu 21 to prevent NetBIOS traffic
from triggering calls and to prevent incoming telnet sessions. A summary of their filter rules is
shown in the figures that follow.
The following figure illustrates the logic flow when executing a filter rule. See also see Figure
173 for the logic flow when executing an IP filter.
