ZyAIR G-2000 Plus User’s Guide
287 Chapter 25 Remote Node Configuration
25.4 Remote Node Filter
Move the cursor to the field Edit Filter Sets in menu 11.1, and then press [SPACE BAR] to
set the value to Yes. Press [ENTER] to open Menu 11.5 - Remote Node Filter.
Use menu 11.5 to specify the filter set(s) to apply to the incoming and outgoing traffic between
this remote node and the ZyAIR to prevent certain packets from triggering calls. You can
specify up to 4 filter sets separated by commas, for example, 1, 5, 9, 12, in each filter field.
Note that spaces are accepted in this field. For more information on defining the filters, please
refer to the Filters chapter. For PPPoE or PPTP encapsulation, you have the additional option
of specifying remote node call filter sets.
Private This field is valid only for PPTP/PPPoE encapsulation. This parameter determines if
the ZyAIR will include the route to this remote node in its RIP broadcasts. If set to
Yes, this route is kept private and not included in RIP broadcast. If No, the route to
this remote node will be propagated to other hosts through RIP broadcasts.
RIP Direction Press [SPACE BAR] and then [ENTER] to select the RIP direction from Both/ None/
In Only/Out Only. See the LAN Setup chapter for more information on RIP. The
default for RIP on the WAN side is None. It is recommended that you do not change
this setting.
Version Press [SPACE BAR] and then [ENTER] to select the RIP version from RIP-1/RIP-2B/
RIP-2M or None.
Multicast IGMP (Internet Group Multicast Protocol) is a network-layer protocol used to
establish membership in a Multicast group. The ZyAIR supports both IGMP version 1
(IGMP-v1) and version 2 (IGMP-v2). Press [SPACE BAR] to enable IP Multicasting
or select None to disable it. See the LAN Setup chapter for more information on this
feature.
Once you have completed filling in Menu 11.3 Remote Node Network Layer Options, press [ENTER]
at the message “Press ENTER to Confirm...” to save your configuration and return to menu 11, or press
[ESC] at any time to cancel.
Table 98 Remote Node Network Layer Options
FIELD DESCRIPTION
