ZyAIR G-2000 Plus User’s Guide
Chapter 25 Remote Node Configuration 286
Figure 139 Menu 11.3 Remote Node Network Layer Options for Ethernet Encapsulation
Menu 11.3 - Remote Node Network Layer Options
IP Address Assignment= Dynamic
Rem IP Addr= N/A
Rem Subnet Mask= N/A
My WAN Addr= N/A
Network Address Translation= SUA Only
Metric= 1
Private= No
RIP Direction= None
Version= N/A
Multicast= None
This menu displays the My WAN Addr field for PPPoE and PPTP encapsulations and
Gateway IP Addr field for Ethernet encapsulation. The following table describes the fields
in this menu.
Table 98 Remote Node Network Layer Options
FIELD DESCRIPTION
IP Address
Assignment
If your ISP did not assign you an explicit IP address, press [SPACE BAR] and then
[ENTER] to select Dynamic; otherwise select Static and enter the IP address &
subnet mask in the following fields.
(Rem) IP
Address
If you have a static IP Assignment, enter the IP address assigned to you by your ISP.
(Rem) IP
Subnet Mask
If you have a static IP Assignment, enter the subnet mask assigned to you.
Gateway IP
Addr
This field is applicable to Ethernet encapsulation only. Enter the gateway IP address
assigned to you if you are using a static IP address.
My WAN Addr This field is applicable to PPPoE and PPTP encapsulations only. Some
implementations, especially the UNIX derivatives, require the WAN link to have a
separate IP network number from the LAN and each end must have a unique
address within the WAN network number. If this is the case, enter the IP address
assigned to the WAN port of your ZyAIR.
Note that this is the address assigned to your local ZyAIR, not the remote router.
Network
Address
Translation
Network Address Translation (NAT) allows the translation of an Internet protocol
address used within one network (for example a private IP address used in a local
network) to a different IP address known within another network (for example a public
IP address used on the Internet).
Choose None to disable NAT.
Choose SUA Only if you have a single public IP address. SUA (Single User Account)
is a subset of NAT that supports two types of mapping: Many-to-One and Server.
Choose Full Feature if you have multiple public IP addresses. Full Feature mapping
types include: One-to-One, Many-to-One (SUA/PAT), Many-to-Many Overload,
Many- One-to-One and Server. When you select Full Feature you must configure at
least one address mapping set!
See the NAT chapter for a full discussion on this feature.
Metric Enter a number from 1 to 15 to set this route’s priority among the ZyAIR’s routes (see
the Metric section in the WAN and Dial Backup Setup chapter) The smaller the
number, the higher priority the route has.
