ZyAIR G-2000 Plus User’s Guide
Chapter 25 Remote Node Configuration 284
The following table describes the fields not already described insee Table 95.
Table 96 Fields in Menu 11.1 (PPPoE Encapsulation Specific)
FIELD DESCRIPTION
Service Name If you are using PPPoE encapsulation, then type the name of your PPPoE service
here. Only valid with PPPoE encapsulation.
Authen This field sets the authentication protocol used for outgoing calls.
Options for this field are:
• CHAP/PAP - Your ZyAIR will accept either CHAP or PAP when requested by
this remote node.
• CHAP- accept CHAP only.
• PAP- accept PAP only.
Telco Option
Allocated Budget The field sets a ceiling for outgoing call time for this remote node. The default for
this field is 0 meaning no budget control.
Period(hr) This field is the time period that the budget should be reset. For example, if we are
allowed to call this remote node for a maximum of 10 minutes every hour, then the
Allocated Budget is (10 minutes) and the Period(hr) is 1 (hour).
Schedules You can apply up to four schedule sets here. For more details please refer to the
Call Schedule Setup chapter.
Nailed-Up
Connection
This field specifies if you want to make the connection to this remote node a nailed-
up connection. More details are given earlier in this section.
Session Options
Idle Timeout Type the length of idle time (when there is no traffic from the ZyAIR to the remote
node) in seconds that can elapse before the ZyAIR automatically disconnects the
PPPoE connection. This option only applies when the ZyAIR initiates the call.
25.2.3 PPTP Encapsulation
If you change the Encapsulation to PPTP in menu 11.1, then you will see the next screen.
Please see the appendix for information on PPTP.
