ZyAIR G-2000 Plus User’s Guide
269 Chapter 23 LAN Setup
Figure 130 Menu 3.5 Wireless LAN Setup
Menu 3.5 - Wireless LAN Setup
Enable Wireless LAN= Yes
ESSID= Wireless
Hide ESSID= No Edit MAC Address Filter= No
Channel ID= CH06 2437MHz Edit Roaming Configuration= No
RTS Threshold= 2432 Breathing LED= Yes
Frag. Threshold= 2432 Preamble= Long
WEP Encryption= 128-bit WEP 802.11 Mode= Mixed
Default Key= 1
Key1= ********
Key2= ********
Key3= ********
Key4= ********
Authen. Method= Auto
Press ENTER to Confirm or ESC to Cancel:
Press Space Bar to Toggle.
The following table describes the fields in this menu.
Table 90 Menu 3.5 Wireless LAN Setup
FIELD DESCRIPTION
ESSID The ESSID (Extended Service Set IDentity) identifies the AP to which the
wireless stations associate. Wireless stations associating to the AP must have
the same ESSID. Enter a descriptive name of up to 32 printable 7-bit ASCII
characters.
Hide ESSID Press [SPACE BAR] and select Yes to hide the ESSID in the outgoing data
frame so an intruder cannot obtain the ESSID through passive scanning.
Channel ID Press [SPACE BAR] to select a channel. This allows you to set the operating
frequency/channel depending on your particular region.
RTS Threshold Setting this attribute to zero turns on the RTS/CTS handshake. Enter a value
between 0 and 2432.
Fragment Threshold This is the maximum data fragment size that can be sent. Enter a value
between 256 and 2432.
WEP Encryption Select Disable to allow wireless stations to communicate with the access points
without any data encryption.
Select 64-bit WEP or 128-bit WEP to enable data encryption.
Default Key Enter the key number (1 to 4) in this field. Only one key can be enabled at any
one time. This key must be the same on the ZyAIR and the wireless stations to
communicate.
