ZyAIR G-2000 Plus User’s Guide
Chapter 20 Introducing the SMT 256
Figure 119 ZyAIR G-2000 Plus SMT Main Menu
Copyright (c) 1994 - 2004 ZyXEL Communications Corp.
ZyAIR G-2000PLUS Main Menu
Getting Started Advanced Management
1. General Setup 21. Filter and Firewall Setup
2. WAN Setup 22. SNMP Configuration
3. LAN Setup 23. System Security
4. Internet Access Setup 24. System Maintenance
26. Schedule Setup
Advanced Applications
11. Remote Node Setup
12. Static Routing Setup
14. Dial-in User Setup
15. NAT Setup
99. Exit
Enter Menu Selection Number:
20.5.1 System Management Terminal Interface Summary
Table 83 Main Menu Summary
# MENU TITLE DESCRIPTION
1 General Setup Use this menu to set up your general information.
2 WAN Setup Use this menu to clone a MAC address from a computer on your LAN.
3 LAN Setup Use this menu to set up your LAN and WLAN connection.
4 Internet Access Setup Configure your Internet Access setup (Internet address, gateway, login, etc.) with
this menu.
11 Remote Node Setup Use this menu to configure detailed remote node settings (your ISP is also a
remote node) as well as apply WAN filters.
12 Static Routing Setup Use this menu to set up static routes.
14 Dial-in User Setup Use this menu to set up local user profiles on the ZyAIR.
15 NAT Setup Use this menu to specify inside servers when NAT is enabled.
21 Filter and Firewall Setup Use this menu to configure filters, activate/deactivate the firewall and view the
firewall log.
22 SNMP Configuration Use this menu to set up SNMP related parameters.
23 System Security Use this menu to change your password.
24 System Maintenance This menu provides system status, diagnostics, software upload, etc.
26 Schedule Setup Use this menu to schedule outgoing calls.
99 Exit Use this to exit from SMT and return to a blank screen.
20.6 Changing the System Password
