ZyAIR G-2000 Plus User’s Guide
Chapter 20 Introducing the SMT 254
Figure 118 ZyAIR G-2000 Plus SMT Menu Overview Example
20.5 Navigating the SMT Interface
The SMT (System Management Terminal) is the interface that you use to configure your
ZyAIR.
Several operations that you should be familiar with before you attempt to modify the
configuration are listed in the table below.
Table 82 Main Menu Commands
OPERATION KEYSTROKE DESCRIPTION
Move down to
another menu
[ENTER] To move forward to a submenu, type in the number of the
desired submenu and press [ENTER].
Move up to a
previous menu
[ESC] Press [ESC] to move back to the previous menu.
