ZyAIR G-2000 Plus User’s Guide
249 Chapter 19 Maintenance
After you see a “restore configuration successful” screen, you must then wait one minute
before logging into the ZyAIR again.
Figure 110 Configuration Upload Successful
The ZyAIR automatically restarts in this time causing a temporary network disconnect. In
some operating systems, you may see the following icon on your desktop.
Figure 111 Network Temporarily Disconnected
If you uploaded the default configuration file you may need to change the IP address of your
computer to be in the same subnet as that of the default ZyAIR IP address (192.168.1.1). See
your Quick Installation Guide for details on how to set up your computer’s IP address.
If the upload was not successful, the following screen will appear. Click Return to go back to
the Configuration screen.
Browse... Click Browse... to find the file you want to upload. Remember that you must
decompress compressed (.ZIP) files before you can upload them.
Upload Click Upload to begin the upload process.
Note: Do not turn off the ZyAIR while configuration file upload is
in progress.
Table 81 Restore Configuration
LABEL DESCRIPTION
