ZyAIR G-2000 Plus User’s Guide
Chapter 18 Log Screens 232
CHAPTER 18
Log Screens
This chapter contains information about configuring general log settings and viewing the
ZyAIR’s logs. Refer to the appendix for example log message explanations.
18.1 Configuring View Log
The web configurator allows you to look at all of the ZyAIR’s logs in one location.
Click the LOGS links under ADVANCED to open the View Log screen. Use the View Log
screen to see the logs for the categories that you selected in the Log Settings screen (see
Figure 99). Options include logs about system maintenance, system errors and access control.
You can view logs and alert messages in this page. Once the log entries are all used, the log
will wrap around and the old logs will be deleted.
Click a column heading to sort the entries. A triangle indicates the direction of the sort order.
Figure 98 View Log
The following table describes the labels in this screen.
Table 73 View Log
LABEL DESCRIPTION
Display Select a log category from the drop down list box to display logs within the
selected category. To view all logs, select All Logs.
The number of categories shown in the drop down list box depends on the
selection in the Log Settings page.
Time This field displays the time the log was recorded.
Message This field states the reason for the log.
