802.11g Wireless 4-port Router User's Guide

ZyAIR G-2000 Plus User’s Guide
203 Chapter 15 Firewall Screens
15.7 Example Firewall Rule
The following Internet firewall rule example allows a hypothetical My Service connection
from the Internet.
1 Click the FIREWALL link and then the Rule Summary tab. Select WA N t o L A N from
the Packet Direction drop-down list box.
Figure 85 Rule Summary
2 In the Rule Summary screen, type the index number for where you want to put the rule,
assuming you have more than one rule. For example, if you type 6, your new rule
becomes number 6 and the previous rule 6 (if there is one) becomes rule 7.
3 Click Create to display the firewall Edit Rule screen.
4 In the Edit Rule screen, select Any in the Destination Address box and then click
Delete.
5 Configure the destination address screen as follows.
