ZyAIR G-2000 Plus User’s Guide
161 Chapter 12 Remote Management Screens
12.6 SNMP
Simple Network Management Protocol (SNMP) is a protocol used for exchanging
management information between network devices. SNMP is a member of the TCP/IP
protocol suite. Your ZyAIR supports SNMP agent functionality, which allows a manager
station to manage and monitor the ZyAIR through the network. The ZyAIR supports SNMP
version one (SNMPv1) and version two (SNMPv2). The next figure illustrates an SNMP
management operation. SNMP is only available if TCP/IP is configured.
Note: SNMP is only available if TCP/IP is configured.
Figure 69 SNMP Management Model
An SNMP managed network consists of two main types of component: agents and a manager.
Secured Client IP
Address
A secured client is a “trusted” computer that is allowed to communicate with the
ZyAIR using this service.
Select All to allow any computer to access the ZyAIR using this service.
Choose Selected to just allow the computer with the IP address that you specify to
access the ZyAIR using this service.
Apply Click Apply to save your customized settings and exit this screen.
Reset Click Reset to begin configuring this screen afresh.
Table 52 Remote Management: FTP
LABEL DESCRIPTION
