ZyAIR G-2000 Plus User’s Guide
Chapter 10 Single User Account (SUA) / Network Address Translation (NAT) 140
The following table summarizes these types.
Table 42 NAT Mapping Types
TYPE IP MAPPING SMT ABBREVIATION
One-to-One ILA1ÅÆ IGA1 1-1
Many-to-One (SUA/PAT) ILA1ÅÆ IGA1
ILA2ÅÆ IGA1
…
M-1
Many-to-Many Overload ILA1ÅÆ IGA1
ILA2ÅÆ IGA2
ILA3ÅÆ IGA1
ILA4ÅÆ IGA2
…
M-M Ov
Many One-to-One ILA1ÅÆ IGA1
ILA2ÅÆ IGA2
ILA3ÅÆ IGA3
…
M-1-1
Server Server 1 IPÅÆ IGA1
Server 2 IPÅÆ IGA1
Server 3 IPÅÆ IGA1
Server
10.2 Using NAT
Note: You must create a firewall rule in addition to setting up
SUA/NAT, to allow traffic from the WAN to be forwarded
through the ZyAIR.
10.2.1 SUA (Single User Account) Versus NAT
SUA (Single User Account) is a ZyNOS implementation of a subset of NAT that supports two
types of mapping, Many-to-One and Server. The ZyAIR also supports Full Feature NAT to
map multiple global IP addresses to multiple private LAN IP addresses of clients or servers
using mapping types. Select either SUA Only or Full Feature in the WAN IP screen.
10.3 SUA Server
A SUA server set is a list of inside (behind NAT on the LAN) servers, for example, web or
FTP, that you can make visible to the outside world even though SUA makes your whole
inside network appear as a single computer to the outside world.
