ZyAIR G-2000 Plus User’s Guide
131 Chapter 9 WAN
9.3 TCP/IP Priority (Metric)
The metric represents the "cost of transmission". A router determines the best route for
transmission by choosing a path with the lowest "cost". RIP routing uses hop count as the
measurement of cost, with a minimum of "1" for directly connected networks. The number
must be between "1" and "15"; a number greater than "15" means the link is down. The
smaller the number, the lower the "cost".
9.4 Configuring WAN IP
To change your ZyAIR’s WAN IP settings, click WA N , then the WAN IP tab. This screen
varies according to the type of encapsulation you select.
If your ISP did not assign you a fixed IP address, click Get automatically from ISP
(Default);otherwise click Use fixed IP Address and enter the IP address in the field provided.
PPTP Configuration
My IP Address Type the (static) IP address assigned to you by your ISP.
My IP Subnet Mask Your ZyAIR will automatically calculate the subnet mask based on the IP
address that you assign. Unless you are implementing subnetting, use the
subnet mask computed by the ZyAIR.
Server IP Address Type the IP address of the PPTP server.
Connection ID/Name Type your identification name for the PPTP server.
Apply Click Apply to save your changes back to the ZyAIR.
Reset Click Reset to begin configuring this screen afresh.
Table 39 PPTP Encapsulation
LABEL DESCRIPTION
