ZyAIR G-2000 Plus User’s Guide
Chapter 8 Internal RADIUS Server 118
8.3 Trusted AP Overview
A trusted AP is an AP that uses the ZyAIR’s internal RADIUS server to authenticate it’s
wireless clients.
The following shows how this is done in two phases.
Figure 45
ZyAIR RADIUS Server Wireless clients. You can
authenticate a maximum of
32 wireless clients using the
ZyAIR’s RADIUS server,
irrespective of the amount of
Trusted AP’s
trusted AP’s configured on
the ZyAIR
.
Trusted AP Overview
1 Configure an IP address and shared secret in the Trusted AP database to authenticate an
AP as a trusted AP.
Issuer This field displays identifying information about the certificate’s issuing certification
authority, such as a common name, organizational unit or department,
organization or company and country. With self-signed certificates, this is the same
information as in the Subject field.
Valid From This field displays the date that the certificate becomes applicable. The text
displays in red and includes a Not Yet Valid! message if the certificate has not yet
become applicable.
Valid To This field displays the date that the certificate expires. The text displays in red and
includes an Expiring! or Expired! message if the certificate is about to expire or
has already expired.
Apply Click Apply to have the ZyAIR use certificates to authenticate wireless clients.
Reset Click Reset to start configuing this screen afresh.
Table 33 My Certificates (continued)
LABEL DESCRIPTION
