ZyAIR G-2000 Plus User’s Guide
117 Chapter 8 Internal RADIUS Server
Figure 44 Internal RADIUS Server Setting Screen
The following table describes the labels in this screen.
Table 33 My Certificates
LABEL DESCRIPTION
Active Select the Active checkbox to have the ZyAIR use its internal RADIUS server to
authenticate wireless clients or other AP’s.
# This field displays the certificate index number. The certificates are listed in
alphabetical order. Certificates can be added or removed in the Advanced
Certificate screens. The internal RADIUS server uses one of the certificates listed
in this screen to authenticate each wireless client. The exact certificate used,
depends on the certificate information configured on the wireless client.
Name This field displays the name used to identify this certificate. The ZyAIR has an
auto_generated_self_signed_cert by factory default. The factory default
certificate is common to all ZyAIR’s that use certificates. You can replace the
certificate when you log into the ZyAIR, see the section Introducing the Web
Configurator or you can go to the Certificates configuration screen, see the
Certificates chapter.
Type This field displays what kind of certificate this is.
REQ represents a certification request and is not yet a valid certificate. Send a
certification request to a certification authority, which then issues a certificate. Use
the My Certificate Import screen to import the certificate and replace the request.
SELF represents a self-signed certificate.
*SELF represents the default self-signed certificate, which the ZyAIR uses to sign
imported trusted remote host certificates.
CERT represents a certificate issued by a certification authority.
Subject This field displays identifying information about the certificate’s owner, such as CN
(Common Name), OU (Organizational Unit or department), O (Organization or
company) and C (Country). It is recommended that each certificate have unique
subject information.
