Chapter 2 Introducing the Web Configurator
P-660HWP-Dx User’s Guide
39
" Click the icon (located in the top right corner of most screens) to view
embedded help.
Table 3 Web Configurator Screens Summary
LINK/ICON SUB-LINK FUNCTION
Wizard INTERNET/
WIRELESS
SETUP
Use these screens for initial configuration including general
setup, ISP parameters for Internet Access and WAN IP/DNS
Server/MAC address assignment.
BANDWIDTH
MANAGEMENT
SETUP
Use these screens to limit bandwidth usage by application or
packet type.
Logout Click this icon to exit the web configurator.
Status This screen shows the P-660HWP-Dx’s general device,
system and interface status information. Use this screen to
access the summary statistics tables.
Network
WAN Internet
Connection
This screen allows you to configure ISP parameters, WAN IP
address assignment, DNS servers and other advanced
properties.
More Connections Use this screen to view and configure other connections for
placing calls to another remote gateway.
WAN Backup
Setup
Use this screen to configure your traffic redirect properties and
WAN backup settings.
LAN IP Use this screen to configure LAN TCP/IP settings, enable Any
IP and other advanced properties.
DHCP Setup Use this screen to configure LAN DHCP settings.
Client List
Use this screen to view current DHCP client information and to
always assign an IP address to a MAC address (and host
name).
IP Alias
Use this screen to partition your LAN interface into subnets.
Wireless LAN General
Use this screen to configure wireless LAN.
OTIST
Use this screen to enable OTIST.
MAC Filter
Use the MAC filter screen to configure the P-660HWP-Dx to
block access to devices or block the devices from accessing
the P-660HWP-Dx.
QoS
Use this screen to configure Wi-Fi Multimedia Quality of
Service (WMM QoS). WMM QoS allows you to prioritize
wireless traffic according to the delivery requirements of
individual services.
Powerline Local Setting
Use this screen to configure the settings of your local power
line enabled device.
Remote Setting
Use this screen to configure the settings of other power line
adapters on your power line network and set up a network.
Status
Use this screen to view the status of your power line network.
