CHAPTER 1
Introducing the P-660HWP-Dx
This chapter introduces the main applications and features of the P-660HWP-Dx. It also
introduces the ways you can manage the P-660HWP-Dx.
1.1 Overview
The P-660HWP-Dx is an IEEE 802.11b/g wireless ADSL2+ gateway that allows super-fast,
secure Internet access over analog (POTS), digital (ISDN) telephone lines (depending on your
model) or by wireless. It also complies with the HomePlug AV standard, enabling networking
using standard electrical wiring.
In the P-660HWP-Dx product name, “H” denotes an integrated 4-port switch (hub) and “W”
denotes an included wireless LAN card that provides wireless connectivity. “P” denotes power
line connection capability.
See the Product Specifications appendix for a full list of features.
Model names ending in “1”, for example P-660H/HW-D Series, denote a device that works
over the analog telephone system, POTS (Plain Old Telephone Service). Model names ending
in “3” denote a device that works over ISDN (Integrated Services Digital Network).
The DSL RJ-11 (ADSL over POTS models) or RJ-45 (ADSL over ISDN models) connects to
your ADSL or ISDN-enabled telephone line.
The included power cable and plug connects to your power line enabled home wiring.
1 Only use firmware for your P-660HWP-Dx’s specific model. Refer to the label on
the bottom of your P-660HWP-Dx.
The P-660HWP-Dx is the ideal high-speed Internet access solution. It is compatible with all
major ADSL DSLAM (Digital Subscriber Line Access Multiplexer) providers and supports
the ADSL standards as shown in Table 1 on page 36. In addition, the P-660HWP-Dx with its
wireless features allows wireless clients access to your wired network resources and to the
Internet.
The P-660HWP-Dx provides protection from attacks by Internet hackers. By default, the
firewall blocks all incoming traffic from the WAN. The firewall supports TCP/UDP inspection
and DoS (Denial of Services) detection and prevention, as well as real time alerts, reports and
logs.
A typical Internet access application is shown below
