Appendix A Product Specifications and Wall Mounting
P-660HWP-Dx User’s Guide
37
Table 137 Wireless Firmware Specifications
Content Filter The P-660HWP-Dx blocks or allows access to web sites that you specify
and blocks access to web sites with URLs that contain keywords that
you specify. You can define time periods and days during which content
filtering is enabled. You can also include or exclude particular computers
on your network from content filtering.
You can also subscribe to category-based content filtering that allows
your P-660HWP-Dx to check web sites against an external database.
Bandwidth Management You can efficiently manage traffic on your network by reserving
bandwidth and giving priority to certain types of traffic and/or to particular
computers.
Remote Management This allows you to decide whether a service (HTTP or FTP traffic for
example) from a computer on a network (LAN or WAN for example) can
access the P-660HWP-Dx.
TR-069 Compliance TR-069 is a protocol that defines how your P-660HWP-Dx can be
managed via a management server such as ZyXEL’s Vantage CNM
Access. The management server can securely manage and update
configuration changes in the ZyXEL Device.
Any IP The Any IP feature allows one computer to connect to the P-660HWP-
Dx (and then to other computers) when their IP addresses are in
different subnets. This is done without changing the network settings
(such as IP address and subnet mask) of the computer.
Traffic Redirect Traffic redirect forwards WAN traffic to a backup gateway when the P-
660HWP-Dx cannot connect to the Internet, thus acting as an auxiliary if
your regular WAN connection fails.
Triple Play The P-660HWP-Dx is capable of simultaneously transferring data, voice
and video over the Internet.
IP Policy Routing (IPPR) Traditionally, routing is based on the destination address only and the
router takes the shortest path to forward a packet. IP Policy Routing
(IPPR) provides a mechanism to override the default routing behavior
and alter the packet forwarding based on the policy defined by the
network administrator.
FEATURE DESCRIPTION
Wireless LAN The P-660HWP-Dx is fully compatible with both IEEE 802.11b and IEEE
802.11g standards and can support both kinds of clients on the same
network.
WEP Encryption WEP (Wired Equivalent Privacy) allows the encryption of data before its
transmission over networks.
Wi-Fi Protected Access
(WPA)
WPA is part of the IEEE 802.11i security specifications standard and
offers user authentication and data encryption.
WPA2 WPA2 is an improvement on WPA with enhanced data encryption, user
authentication and key management.
WPA2-PSK WPA(2)-PSK: WPA-PSK and WPA2-PSK allow you to implement the
superior WPA and WPA2 encryption standards without using a RADIUS
server. Instead, WPA(2)-PSK uses pre-shared keys (PSKs) to
authenticate devices on the wireless network.
Table 136 Firmware Specifications
FEATURE DESCRIPTION
