Chapter 16 Dynamic DNS Setup
P-660HWP-Dx User’s Guide
36
Figure 135 Dynamic DNS
The following table describes the fields in this screen.
Table 97 Dynamic DNS
LABEL DESCRIPTION
Dynamic DNS
Setup
Active Dynamic
DNS
Select this check box to use dynamic DNS.
Service Provider This is the name of your Dynamic DNS service provider.
Dynamic DNS
Type
Select the type of service that you are registered for from your Dynamic DNS
service provider.
Host Name Type the domain name assigned to your P-660HWP-Dx by your Dynamic DNS
provider.
You can specify up to two host names in the field separated by a comma (",").
User Name Type your user name.
Password Type the password assigned to you.
Enable Wildcard
Option
Select the check box to enable DynDNS Wildcard.
Enable off line
option
This option is available when Custom DNS is selected in the DDNS Type field.
Check with your Dynamic DNS service provider to have traffic redirected to a URL
(that you can specify) while you are off line.
IP Address
Update Policy
Use WAN IP
Address
Select this option to update the IP address of the host name(s) to the WAN IP
address.
