Chapter 13 Certificates
P-660HWP-Dx User’s Guide
53
Figure 123 Security > Certificates > Trusted Remote Hosts > Details
The following table describes the labels in this screen.
Table 80 Security > Certificates > Trusted Remote Hosts > Details
LABEL DESCRIPTION
Certification Name This field displays the identifying name of this certificate. If you want to change
the name, type up to 31 characters to identify this key certificate. You may use
any character (not including spaces).
Certificate Path Click the Refresh button to have this read-only text box display the end entity’s
own certificate and a list of certification authority certificates in the hierarchy of
certification authorities that validate a certificate’s issuing certification authority.
For a trusted host, the list consists of the end entity’s own certificate and the
default self-signed certificate that the P-660HWP-Dx uses to sign remote host
certificates.
Refresh Click Refresh to display the certification path.
Certificate
Information
These read-only fields display detailed information about the certificate.
Type This field displays general information about the certificate. With trusted
remote host certificates, this field always displays CA-signed. The P-660HWP-
Dx is the Certification Authority that signed the certificate. X.509 means that
this certificate was created and signed according to the ITU-T X.509
recommendation that defines the formats for public-key certificates.
Version This field displays the X.509 version number.
Serial Number This field displays the certificate’s identification number given by the device
that created the certificate.
