802.11g HomePlug AV ADSL2+ Gateway User's Guide

Chapter 13 Certificates
P-660HWP-Dx User’s Guide
44
After you click Apply in the My Certificate Create screen, you see a screen that tells you the
P-660HWP-Dx is generating the self-signed certificate or certification request.
After the P-660HWP-Dx successfully enrolls a certificate or generates a certification request
or a self-signed certificate, you see a screen with a Return button that takes you back to the
My Certificates screen.
If you configured the My Certificate Create screen to have the P-660HWP-Dx enroll a
certificate and the certificate enrollment is not successful, you see a screen with a Return
button that takes you back to the My Certificate Create screen. Click Return and check your
information in the My Certificate Create screen. Make sure that the certification authority
information is correct and that your Internet connection is working properly if you want the P-
660HWP-Dx to enroll a certificate online.
13.8 My Certificates > Import
Click Security > Certificates > My Certificates and then Import to open the My Certificate
Import screen. Follow the instructions in this screen to save an existing certificate from a
computer to the P-660HWP-Dx.
Enrollment Protocol Select the certification authority’s enrollment protocol from the drop-down list
box.
Simple Certificate Enrollment Protocol (SCEP) is a TCP-based enrollment
protocol that was developed by VeriSign and Cisco.
Certificate Management Protocol (CMP) is a TCP-based enrollment
protocol that was developed by the Public Key Infrastructure X.509 working
group of the Internet Engineering Task Force (IETF) and is specified in RFC
2510.
CA Server Address Enter the IP address (or URL) of the certification authority server.
CA Certificate Select the certification authority’s certificate from the CA Certificate drop-
down list box.
You must have the certification authority’s certificate already imported in the
Trusted CAs screen. Click Trusted CAs to go to the Trusted CAs screen
where you can view (and manage) the P-660HWP-Dx's list of certificates of
trusted certification authorities.
Request
Authentication
When you select Create a certification request and enroll for a certificate
immediately online, the certification authority may want you to include a
reference number and key to identify you when you send a certification
request. Fill in both the Reference Number and the Key fields if your
certification authority uses CMP enrollment protocol. Just fill in the Key field if
your certification authority uses the SCEP enrollment protocol.
Key Type the key that the certification authority gave you.
Back Click Back to go the previous screen
Apply Click Apply to begin certificate or certification request generation.
Cancel Click Cancel to quit and return to the My Certificates screen.
Table 73 Security > Certificates > My Certificates > Create (continued)
LABEL DESCRIPTION
