Chapter 11 Firewall Configuration
P-660HWP-Dx User’s Guide
49
3 Is it possible to modify the rule to be more specific? For example, if IRC is blocked for
all users, will a rule that blocks just certain users be more effective?
4 Does a rule that allows Internet users access to resources on the LAN create a security
vulnerability? For example, if FTP ports (TCP 20, 21) are allowed from the Internet to
the LAN, Internet users may be able to connect to computers with running FTP servers.
5 Does this rule conflict with any existing rules?
6 Once these questions have been answered, adding rules is simply a matter of plugging
the information into the correct fields in the web configurator screens.
11.3.3 Key Fields For Configuring Rules
11.3.3.1 Action
Should the action be to Drop, Reject or Permit?
" “Drop” means the firewall silently discards the packet. “Reject” means the
firewall discards packets and sends an ICMP destination-unreachable message
to the sender.
11.3.3.2 Service
Select the service from the Service scrolling list box. If the service is not listed, it is necessary
to first define it. See Section Table 64 on page 61 for more information on predefined services.
11.3.3.3 Source Address
What is the connection’s source address; is it on the LAN or WAN? Is it a single IP, a range of
IPs or a subnet?
11.3.3.4 Destination Address
What is the connection’s destination address; is it on the LAN or WAN? Is it a single IP, a
range of IPs or a subnet?
11.4 Connection Direction
This section describes examples for firewall rules for connections going from LAN to WAN
and from WAN to LAN.
LAN to LAN/ Router and WAN to WAN/ Router rules apply to packets coming in on the
associated interface (LAN or WAN respectively). LAN to LAN/ Router means policies for
LAN-to-P-660HWP-Dx (the policies for managing the P-660HWP-Dx through the LAN
interface) and policies for LAN-to-LAN (the policies that control routing between two subnets
on the LAN). Similarly, WAN to WAN/ Router polices apply in the same way to the WAN
port.
