Non-Interpretive 12-Lead ECG Monitoring
10 9650-1215-01 Rev. C
2x6 Format (Fax Report Only)
The 2x6 Format prints all 12-lead ECG data recorded during the first 5 second interval. The 2x6 format inhibits printing
of the lead II rhythm strip normally printed on the fax page. The stripchart always prints in the 4x3 format.
Fax the 2x6 format immediately after acquisition. The 2x6 fax image is not stored in the patient records. You can,
however, reproduce patient data in 4x3 format at a later time.
Patient Information
DEVICE ID: 00000000000
RECORDED: 16: 09:27 31 MAY 05
PATI ENT NAME : JOE SMITH
PATIENT ID: 200505311609
PATI ENT AGE: 60
PATI ENT SEX: Mal e
Vent. Rate : 60
