YOUR LOCAL SUPPLIER For all you pool needs, visit www.zodiac.com.au Zodiac is a registered trademark of Zodiac Group Australia Pty Ltd ABN 87 002 641 965 Zodiac Group Australia: PO box 7238 Wetherill Park, 2164 NSW, Australia Tel: 1800 688 552 Fax: 1300 781 688 © Copyright Zodiac Australian Ltd 2009 Ei Brochure A4 Spread 090701.
CONTENTS OF THE CARTON Ei has been designed to be the world’s simplest saltwater chlorine generator. Simple to install, operate and maintain, the Ei will provide you many years of trouble free operation and keep your pool safe and sparkling for the whole family to enjoy. Practices Act 1974 ) is limited, at Zodiac’s option, to the repair or replacement of the Product or the payment of the cost of having the Product repaired or replaced.
YOUR COMPLETE FILTRATION SYSTEM d. e. f. g. h. i. j. k. Any failure, to the extent that the failure is not a failure of the Product to perform in accordance with its specifications or results from a defect in its materials or workmanship. Replacement or repair of any lost or stolen parts or accessories. Discoloration of the Product caused by prolonged UV exposure or reaction to chemicals used in the pool water.
At Zodiac, we take safety seriously. The Ei is designed with many in built safety features but you should always exercise caution when using electrical appliances and follow the instructions closely. Failure to do so could result in permanent injury, electrocution or drowning. 4) When outside of the manufacturers build date a proof of purchase (i.e. bill of sale, invoice or purchase receipt) may be required when making a claim under this warranty.
GENERAL WARNINGS WARRANTY ZODIAC WARRANTY TERMS AND CONDITIONS Subject to the terms and conditions set out below, Zodiac Group Australia Pty Ltd (ABN 87 002 641 965) (“Zodiac”) agrees to repair or replace at Zodiac’s cost the Zodiac product which this warranty card accompanies (“the Product”), and any Zodiac component supplied with it, originally purchased by you from a Zodiac Authorised Dealer when the Product does not perform in accordance with the manufacturer’s specifications or is otherwise defective
CLEANING THE CELL ELECTRICAL HAZARD To avoid accidental contact with lawn mowers and hedge ....................trimmers, power cords should remain within sight and above ground at all times. The Zodiac Ei Power pack must not come into contact with water and should be installed at least 3 metres from the inside wall of your swimming pool. Should a lack of water be detected, the unit’s electronic flow switch is designed to turn off the system.
BACKUP BATTERY The Ei is fitted with a long life battery. This battery should last in excess of 500 hours without the mains being connected. The battery will retain ALL settings in the event of a power failure. In addition the Microprocessor in the unit will retain some settings permanently, in the event of the battery going flat or being replaced: - Operating hours Cell hours Controller setting ERRORS / WARNINGS NO FLOW Diagnosis: Insufficient water flow in the cell.
24 HOUR SAFETY TIMEOUT Less than 1.5m 3) Plug it into the power point but do not turn on yet 4) Ensure placement of Ei cell on pipe is no more than 1.5m from power pack To prevent the possibility of hazardous over-chlorination, the Ei has a built-in safety shutdown. If the Ei is manually turned ON (with no timers set), and left on, chlorine generation will automatically turn OFF after 24 hours. The Ei can be turned ON as normal after this time.
AUTOMATIC PUMP PROTECTION The Ei chlorine generator has an in-built pump protection feature (when the Ei pump output is used). This feature is designed to prevent pump damage due to the pump running dry. The pump protection feature operates in the following way: If a ‘no flow’ situation occurs for more than 3 minutes, while the pump output is turned ON, the pump will automatically turn OFF. At this point ‘CHECK EQUIPMENT!’ is displayed on the screen.
SETTING THE OUTPUT LEVEL CONTROL PANEL When setting the chlorine output level you must consider the size of the pool, the amount of use the pool will be receiving and how hot the weather is. All these factors weigh greatly on the level of output needed. Simply adjust the output level needed using the following steps.
MANUAL OPERATION SETTING THE CLOCK In addition to running off a timer, the Ei can also be operated manually 1) Apply power to the Ei unit by pressing the 2) Wait for the start up sequence to finish (~5 seconds) 3) Press and hold the 4) While holding the button. The Ei will run until the next ‘OFF’ time is reached, then will operate from the timers.
SETTING THE TIMERS The Ei has 2 ON/OFF timers available, which can be set to enable the chlorinator (and pump if connected) to run up to 2 times each day. For most pools we recommend running your filtration equipment 4hrs in the morning and evening during summer, and 3hrs in the morning and evening during winter.
