Owner's manual

24
Network
Settings
Command Port Click into sub menu screen. 5050
Media Port Click into sub menu screen. 6050
PPPoE Setting ON,OFF, Click into sub menu screen. Off
PPPoE address Click into sub menu screen. 0.0.0.0
DNS address Click into sub menu screen. 0.0.0.0
Dynamic Domain Name ON,OFF Off
Auto Register ON,OFF Off
File Sharing Click to select or disselect Off
Email Setting Click into sub menu screen
Mobile Port Click into sub menu screen. 7050
UPnP setting Off, on, click into sub menu screen Off
Off, on, click into sub menu screen Off
Off, on, click into sub menu screen Off
Off
Off
Dedicated server
FTP setting
IP white/black list
Off, white list, black list, click into
sub menu screen
Time synchronized Off, on, click into sub menu screen
Alarm Input Type
Alarm
settings
N/O. N/C. N/O.
Event Handling
record, PTZ preset, zoom out, alarm out ,
buzzer , upload, email
Trigger alarm output,
buzzer and email
Alarm Setting Off,1-10 ON
Alarm Zoom Out 1-10 seconds, Off Off
Abnormal device
click into sub menu screen :alarm out, buzzer,
upload, email
all
Gateway Click into sub menu screen. 192.168.0.1
HTTP Port Click into sub menu screen. 80
4 Introduction of Mobile phone Monitor
1) Configuration of server (DVR)
Setup device,type in user name and password to log in.
Shown as the figure V1-3 below, click 【Net】and then click 【Next Page】to enter into screen of【Mobile
port】.
Shown as the figure V1-4 below, modify port, the default port number of mobile phone is 7050.
Right click mouse or click 【Save】 to save and exit.
Shown as the figure V1-5 below, click 【Record】 and then select 【ON】in the sub menu of 【Sub Code】
column.
FigV 1Screen of DVR network configuration FigV 2Screen of DVR mobile phone port configuration
