Installation Guide ZL400 Version: 1.
Diagram and Caution Diagram G P K O K N J H M A L B I D F H S E A C T 1 R Q
Caution Do not overexert when tighten the screws. Do not use electric tool to tighten the screws.
Installation Step 1. Align the template along the vertical center line of the mortise at the desired handle height, and tape it to the door. Drill the hole on the door.
2.
3. Install mortise (A) 4. Install mortise latch plate (C) B D B A D C Note: Two Triangles on the mortise must be in horizontal alignment (as the above enlarged figure).
5.
6. Install 8x8 spindle (H) and fix outdoor unit (I) K J K J K H H H I H Note: Please confirm the two triangles of the mortise be in horizontal position always! As step3 in this installation instruction.
7.
8. Install batteries (N) 9.
10. Test lock Maintenance 1. Test lock by rotating handle and emergency key. 2. You can use emergency key by removing the cover on the lock cylinder with screwdriver or nails. 1. Avoid contacting with corrosive substances. 2. Do not hang objects on the handle. 3. When battery power is lower, the lock will beep to remind user to renew the batteries. 4. Please do not mix up positive and negative while replacing battery. 5. To avoid leaking, it is better to renew battery at least once in half year.
FCC warning: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, (2) This device must accept any interference received, including interference that may cause undesired operation. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. No.
