Installation Manual
1
2
Connecting the wires
3
Installing the wall xture
Install the mounting bracket
TOOLS REQUIRED FOR INSTALLATION
AND ASSEMBLY
(not included):
Safety
goggles
Wire
strippers
Phillips
screwdriver
Electrical
tape
Wire
cutters
Flathead
screwdriver
Installation
WARNING: Installation must be performed by a
qualied licensed electricion.
DANGER: Before installation, turn o the main
power at the circuit breaker.
A. Connect the white supply wire to the white xture wire.
B. Connect the black supply wire to the black xture wire.
C. Connect the ground supply wire to the ground xture wire.
D. Use wire nuts to secure all connections.
B. Install the xture threaded rods through the backplate
Install and tighten the Fixture Mounting Decorative
Nuts so that the backplate is secured ush
against the wall.
C. Install the Glass Globe with the threaded nuts.
Do not over tighten. Install the light bulbs.
A. Pull the power supply wires out from the outlet box.
Thread the Fixture Mounting Screws (B) through the
Mounting Bracket (A) into the junction box, as shown.
A. Carefully tuck the xture wires into the junction box.
Mounting Screws
Wall Mounting Plate
Outlet Box
Wire Nuts
Green Ground Screw
E26 Bulbs
Socket Nut
Glass Globe
Socket
Mounting Nuts
Backplate
BLACK Supply Wire
BLACK Fixture Wire
WHITE Fixture Wire
WHITE Supply Wire
GROUND Supply Wire
GROUND Fixture Wire
