User Manual

802006 - Sparkling HT- BCS; BCSHA -AV; User Guide - July 2015 - V2.00 Page 23 of 28
To change the Filter: (See also Section C)
• Open the door of the under sink unit.
• Relieve system pressure via the filter flush stop cock, a quick open and
close will do. Use the bucket to catch the discharge.
• Grasp filter cartridge, depress the red lever at the top right of the filter and
rotate the cartridge a quarter turn to the left, then gently pull down.
Water Filter
The Zip HydroTap notifies when filter replacement is due. If you notice one of
the following, you will need to change the filter:
• The Change Filter light will flash white once a second and remain so until
reset.
• The filter percentage will show 0% on the Home screen.
Note: Depending on local water quality conditions and usage, the filter
may require changing anywhere from 500 Litres to 10,000 Litres. You may
also need to replace the filter if you notice unpleasant odours or tastes.
Some water may drip from the filter
head (socket) during replacement.
Keep a towel handy to dry up any
drips.
Filter Maintenance
Dispense Times
The ability to change the maximum dispensing time for both the hot and cold
water has been introduced. The default settings for the maximum dispensing
times is 15 seconds. Here, the operator may change both the hot and cold
dispensing times to between 5 and 15 seconds, in increments of 1 second.
LCD Screen operation - Section G
1. Press the [MENU] button for main
menu.
2. Press the [Setting] button.
3. Press the [Dispense Time] button.
4. Select the option to change and
scroll using the up and down
arrow Keys
To edit the dispensing times:
