ZIP HydroTap G4 ® User Guide • • • • Tap Operation..................(Pages 2-10) LCD Screen & Menu .......(Pages 11-22) Maintenance.................... (Pages 23-26) Home Menu Icons............(Page 27) Date of Installation............../........../.......... BCS Residential Affix Model Number Label Here 802006 802006 - Sparkling HT- BCS; BCSHA-AV; Residential User Guide - July 2015 - V2.
Tap Safety 3. The safety lock feature is provided to prevent boiling water flowing if the hot lever is inadvertently operated. This function can be activated and deactivated from either the Tap or from the touch screen display (Located on the unit in the cupboard). To set the tap safety setting: (Classic; Elite & All-In-One taps) 1. Press [MENU] button for main A menu. 2. Press [Setting] button. 3. Press [Safety] button. 4.
. Tap functions Elite Tap: Boiling Button The Elite tap uses touch sensitive controls, to dispense Boiling, Chilled and Sparkling water. Chilled Button Safety Lock When operating the tap, ensure the touch surface is dry as moisture may interfere with the sensor touch control. The safety lock can be controlled from either the tap or from the touch screen display in the same way as the Classic tap (See page 2) All-In-One Tap: The top of the All-In-One tap is operated the same as a Classic HydroTap.
Tap functions HydroTap Arc/Cube: 3. On powerup, wait 30secs. for the unit to calibrate itself. Tapping the select button will allow the choice of Boiling (RED) with safety, Chilled (BLUE) or Sparkling (WHITE) water mode. The Arc/Cube control may be rotated in a forward or reverse direction to dispense Boiling or Chilled water. The rotary control is spring loaded in the anticlockwise direction and when released, Rotary control will return to the OFF position.
3. Tap operation To dispense chilled water: Classic Tap HydroTap Classic and All-In-One taps: Press or pull lever Depressing the “Blue” lever allows the dispensing of chilled water. Pulling forward the Blue lever allows the tap to operate in a “no-touch” mode. Water will flow from between 5 and 15 seconds (This is user adjustable). To reset, return the handle to the “Off” position and repeat the step. The lever has to be manually returned to the “Off” position.
Tap operation 3. To dispense boiling water: (With the safety OFF) HydroTap Classic: Depressing the Red lever allows the dispensing of boiling water. Pulling forward the Red lever allows the tap to operate in a “no-touch” mode. Water will flow from between 5 and 15 seconds (This is user adjustable). To reset, return the handle to the “Off” position and repeat the step. The lever has to be manually returned to the “Off” position.
Tap operation To dispense Sparkling water: Operate both levers together HydroTap Classic and All-In-One taps: Depressing both the ‘Red’ and the ‘Blue’ levers allows the HydroTap Classic dispensing of Sparkling water. Pulling forward both levers allows the tap to operate in a in a “no-touch” mode. Water will flow from between 5 and 15 seconds (This is user adjustable). To reset, return the handles to the “Off” position and repeat the step. The levers have to be manually returned to the “Off” position.
Tap lights Red Boiling Water Light: (All) Red Lights Blue Lights On all the time: This indicates that the boiling water is ready. Flashing slowly: This indicates that the boiling water is below the desired temperature. Wait for the light to stop flashing before dispensing water. The flashing light will typically occur after switching on, or coming out of sleep mode.
Filter Lights Filter light Filter light: Classic; Elite & AIO Filter Light Off: This indicates the filter is operating within its normal specified lifespan. Filter Change light flashing slowly: The light will flash slowly when the filter is due for replacement and the LCD will show “Filter Change”. Refer to “Replacing the filter” in section ‘C’ of this document. Classic Tap Filter Light Turn filter light OFF: (All models) Refer to “Filter Reset” in section ‘C’ of this document.
Safety Sensor Calibration (lever models) Light intensity varies from site to site, therefore it is recommended that a re-calibration be performed at the time of the installation. All direct natural sun light must be shaded from the HydroTap, during the calibration. This can be achieved by closing any nearby curtains, blinds, etc. or by shading the tap with a dark cloth. 1. With the unit in Normal operating mode and with the safety enabled 2. 3. Turn the power OFF 4. 5. 6. Turn ON the power 7.
3LCD Screen Zip HydroTap G4 introduces a ‘TOUCH’ screen for easy setup and operation adjustment. (See page 27 for Home Menu Icons) Other possible messages in status window: Status** Information Notes Safety OFF Product is in normal operation mode - Safety ON Safety lock is activated Refer to section G - safety System Fault Product has one or more system faults Refer to section B Sleep Mode System is in sleep mode. Boiling Refer to section water or hot water is not available.
3LCD Main Menu Language Information Screen Menu Sub Menu Sub Menu Options Section • English • Deutsch A • Product Info • System Faults • Product serial no.
A LCD Screen operation - Section A Set Language 1. Press [MENU] for main menu. 2. Press [Language] button. 3. Select the country to change the language 4. Press [<=] button for the previous menu LCD Screen operation - Section B B System Information In this section, you can find product information, system faults and check the filter logs of your product. 1. Press the [MENU] button for main menu. 2. Press the [Info] button to view the product serial number and other key information 1.
LCD Screen operation - Section C Install C Once your Zip HydroTap G4 unit has been installed, Go to Install menu to configure the system settings for your product. Sub menu: 1. - Filter Flush 2. - Filter Reset 3. - Boiling Calibration 4. - Booster 5. - Purge CO2 6. - Lux Sensor Calibration 1. - Filter Flush Have a 10L bucket or similar container (not supplied) at the ready to hold a quantity of water that will be ejected while the Filter Flush Mode is in operation.
LCD Screen operation - Section C 2. - Filter Reset After replacing the filter, the counters should be reset 1. Press the [MENU] button for main menu. 2. Press the [Install] button. 3. Press the [Filter Reset] button. 4. To set the filter life or edit filter usage, refer to section G- Filter. 3 - Boiling Calibration Caution: During calibration, boiling water units may vent steam from the tap spout. Take care to avoid personal injury whenever this occurs.
LCD Screen operation - Section C 5 - Purge CO2 When fitting a new gas bottle, it is important to purge the gas lines. 1. Press the [MENU] button for main menu. 2. Press the [Install] button. 3. Press the [Purge CO2] button. 4. In the next screen, press the 5. 6. 7. 8. [START] button to commence the purging process. Wait for the water to stop flowing through the unit. Wait a further 10 seconds after the water has stopped flowing. During this time you will hear the CO2 gas escaping through the tap.
3. E LCD Screen operation - Section E Security The Zip HydroTap G4 allows the appliance coordinator to set up a password to protect against users changing the preferred system settings. To set a password 1. Press [MENU] button for main menu. 2. Press [Security] button. 3. Press [Enable Password} 4. Enter a 4 digit password To change a password 1. Press [MENU] button for main menu. 2. Press [Security] button. 3. Press [Change Password} 4. Enter your old 4 digit password 5.
3. LCD Screen operation - Section G g Instructions G Settings If, in section E, you have set a password, then you will need to enter your password to access the settings screens. If you have forgotten the password, please disconnect the power and restart your HydroTap unit. 1. Press [MENU] button for main menu. 2. Press [Settings] button. 4. Then enter your 4-digit password. Set Date / Time 1. Press [MENU] button for main menu. 2. Press [Setting] button. 3. Press [Date/Time] button. 4.
3. LCD Screen operation - Section G t 1. Press [MENU] button for main menu. 2. Press [Temperature] button. 3. To adjust the temperature, press the relevant temperature button and then use the up and down arrows. Filter Zip HydroTap G4 allows the user to adjust filter life and edit filter usage. Note: The filter life may be set as a function of Litres used, or in months from the filter change. When the first of these functions is reached (i.e.
LCD Screen operation - Section G 3. Energy Modes This mode allows the HydroTap to enter into Energy Saving mode. There are two options available: ‘Sleep’ mode and ‘ON/OFF’ mode. In Sleep Mode the unit will go to “Sleep” after a 2hr period of inactivity. The Boiling water will gradually drop to either 68°C or room temp, as shown in the table below and the Chilled water will be ON or OFF. When the period of inactivity passes, the home screen status window will show “Sleep Mode”.
LCD Screen operation - Section G Note: Any attempt, during OFF mode, to dispense water, will bring the unit out of sleep mode. The unit will return to sleep mode after 2 hours of non use. Please allow sufficient time for the water to reach the set temperature after disabling the sleep mode. In ON / OFF Mode the user may turn the unit ON or OFF at specific times for individual days or alternatively by weekly and/or weekend settings. To activate ON/OFF mode: 1. Press the [MENU] button for main 2. 3. 4. 5. 6.
LCD Screen operation - Section G Safety To set the tap safety setting: • Press [MENU] button for main menu. • Press [Setting] button. • Press [Safety] button. • Press button A - YES to allow the safety setting to be changed on the Tap A B C * To Enable or Disable the safety on the tap • Press button B to select Enable / Disable Hot Isolation: (Not available for HydroTap Arc/Cube) * The HydroTap is equipped with a safety mode that allows for additional safety protection, if needed.
LCD Screen operation - Section G Dispense Times The ability to change the maximum dispensing time for both the hot and cold water has been introduced. The default settings for the maximum dispensing times is 15 seconds. Here, the operator may change both the hot and cold dispensing times to between 5 and 15 seconds, in increments of 1 second. To edit the dispensing times: 1. Press the [MENU] button for main menu. 2. Press the [Setting] button. 3. Press the [Dispense Time] button. 4.
Filter Maintenance • Caution: a small amount of water will drip as the cartridge is removed. • Do not tilt the cartridge as water may spill from it if tilted. • Unpack replacement cartridge and remove sanitary cap, write today’s date where shown on the label. • Avoid touching the filter O-rings and filter opening as this may cause bacterial contamination of the cartridge.
Gas bottle change 1. Turn the CO2 bottle regulator OFF (Anti-clockwise). The knob will screw 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. up and away from the bottle. Remove the bottle from the cupboard and disconnect the regulator. If the braided hose is removed from the regulator, be careful not to loose the small plastic sealing olive, located inside the end of the hose. Fit the regulator and hose assembly to the new gas bottle. Be aware that some CO2 may be discharged from the bottle joint.
Cleaning General cleaning Do not use strong, corrosive, spray or abrasive cleaners. Clean with a soft damp cloth and mild soap. Under sink units must never be located near, or cleaned with water jets. Avoid using airborne pesticides near the undersink unit. Page 26 of 28 802006 - Sparkling HT- BCS; BCSHA-AV; User Guide - July 2015 - V2.
Home Menu Icons Safety switch is LOCKED. The HydroTap will not dispense any Boiling water. See page 2 for safety switch operation Safety switch is UNLOCKED. Boiling water may be dispensed. See page 6 for tap operation details Sleep mode is active. There are 7 sleep mode options which display this icon on the home screen. See page 20 for details. Heater is in OFF mode. When this icon is displayed, no power is being supplied to the heating element. See pages 20 and 21 for Energy Mode options.
