User's Manual

Wireless
802.11g/b Adapter
ZC-WL0159 is a high-gain wireless PIN Interface adapter
which provides a simple and easy way to add or upgrade
wireless connectivity to your desktop or notebook
computer. You can just plug it into computer's
A-type
USB 2.0 Connector
port and enjoy incredible high-speed
wireless network access.
 Complies with IEEE 802.11g; 802.11b standard for
2.4GHz Wireless LAN.
 Supports Ad-Hoc/Infrastructure modes
 Supports PC Card hot-SWAP and true Plug & Play.
 Works with all existing network infrastructure.
 Supports Wi-Fi Protected Setup (WPS) configuration
function
 Capable of up to 128-Bit WEP Encryption.
 Freedom to roam while staying connected.
 22-Mbps Packet Binary Convolution Coding (PBCC)
(according to the IEEE Std 802.11b high-rate
specification ).
 UP to 54 Mbps High-Speed Transfer Rate in 802.11g
mode of operation.
 Rich diagnostic LED indicators with Integrated Antenna.
 Supports Windows 2000, XP32/64,Vista32/64,
Linux,Mac
 Low power consumption.
 Easy to install and configure.
Standard
IEEE802.11g; IEEE 802.11b
Modulation
Type
OFDM with BPSK, QPSK,
16QAM,64QAM (11g)
BPSK, QPSK, CCK (11b)
Interface
4PIN Interface
Frequency
2.4~2.4835 GHz
Transmission
Distance
Indoor up to 100m , outdoor up to
300m (it is limited in an
environment)
Data Rate
11b 1/2/5.5/11Mbps
11g 6/9/12/24/36/48/54Mbps
Auto fallback
Transmit Powe
r
15 dBm (Typical)
Data Security
64/128-bit WEP Data Encryption,
WPA (TKIP with IEEE 802.1x) and
AES
LED Indicator
Link/Activity
Operating
Temperature
0 ~ 55℃
Storage
-40°C~70°C (-40℉~158℉)
Humidity
5 ~ 95% non-condensing
Operating
System
Windows 2000, XP32/64,
Vista32/64, Linux,Mac
WIFI MODULE
IEEE 802.11g/b
Model No: WL0159
Product Description
Product Features
Product Specification
