3. Device Installation
3.1 Installation Environment
Try to avoid intense direct light and intense backlighting scenes when installing the
device. Please keep the ambient light bright.
3.2 Tools Preparations
 Phillips screwdriver
 Antistatic wrist strap or antistatic gloves
 Drill
 Tape measure
 Marker
 Plenty of silicone rubber
 Silicone gun
3.3 Device Wiring
1 Wiring Embedding
Before installing the access control terminal, plan the layout of cables, including the
power cable, network cable, door lock cable, alarm cable, and RS485 cable. The
number of cables depends on the actual networking conditions. For details, see
Wiring Description.
2 Wiring Description
The figures below show the wiring between the access control terminal and different
devices. For the wiring terminal of each device, see the operation manual of the
device or consult related manufacturers.
NOTE!
In the wiring schematic diagrams, input devices and output devices are defined as
follows:

Input devices refer to devices that send signals to the access control terminal.

Output
devices refer to devices that receive output signals from the access
control terminal.
