Specification Sheet

Specications subject to change, check zephyronline.com for up-to-date information.
Zephyr Ventilation | 2277 Harbor Bay Parkway, Alameda, CA 94502 | 888.880.VENT
Stainless Steel
Size
BLOWER PERFORMANCE
Blower CFM (Min. - Max.)
Sones (Min. - Max.)
FEATURES
Controls
Speed Levels
Auto Delay-O
Lighting
Dual-Level Lighting
Filters
Perimeter Aspiration System
Recirculating Option
DUCT SPECIFICATIONS
Vertical Internal Blower
Horizontal Internal Blower
AC POWER
OPTIONAL ACCESSORIES
Recirculating Kit
Damper, 7” Round
MOUNTING HEIGHT RANGE*
WARRANTY
ZPY-E30BS
30”
210 - 400
2 - 5
Mechanical Slide
3
No
LumiLight LED, 6W x2
Yes
Aluminum Mesh x2
Yes
Yes
7” Round or 3-1/4” x 10”
3-1/4” x 10”
120V, 60Hz at Max. 2A
ZRC-00PY
AK00067
24” - 32”
3 years parts, 1 year labor
MAY21.0101
ZPY-E36BS
36”
210 - 400
2 - 5
Mechanical Slide
3
No
LumiLight LED, 6W x2
Yes
Aluminum Mesh x2
Yes
Yes
7” Round or 3-1/4” x 10”
3-1/4” x 10”
120V, 60Hz at Max. 2A
ZRC-00PY
AK00067
24” - 32”
3 years parts, 1 year labor
ZPY-E30BS290
30”
120 - 290
1.1 - 3.2
Mechanical Slide
3
No
LumiLight LED, 6W x2
Yes
Aluminum Mesh x2
Yes
Yes
7” Round or 3-1/4” x 10”
3-1/4” x 10”
120V, 60Hz at Max. 2A
ZRC-00PY
AK00067
24” - 32”
3 years parts, 1 year labor
*Mounting height refers to distance between top of a 36” tall cooking surface and bottom of hood.
UNDER-CABINET
CORE
PYRAMID
MODEL
ZEPHYRONLINE.COM
DID YOU KNOW?
The Perimeter Aspiration System moves airow away from the central area
of the hood and evenly distributes it through narrow openings around the
perimeter of the hood. This ventilation method increases air velocity and
improves the capture of cooking contaminants.
