Specifications

Accessories
Zephyr Fans
11
277 Volt Transformer
To meet local requirements voltage
transformers are available for all
Zephyrs.
Pilot Light
This amber colored light
easily snaps into any
opening in the Zephyr
grille. The light will indicate
when the fan is in opera-
tion and is ideal when fan
is not interlocked with
lights.
Motion Sensor
For applications where automated operation
of the fan is required, a motion detector can
be used to turn the fan on or off. The sensor
features full scanning capabilities and can be
placed anywhere within the room. The sen-
sor also offers adjustable shutoff feature with
delays of up to 15 minutes.
Square To Round Transition
Designed to make the installation of
flex duct quick and easy. Available to
accommodate the most common flex
duct sizes.
Two Speed Switch
A PennBarry Exclusive. The deco-
rator, three position center off, two
speed switch is designed to work
with PennBarry’s EasyTap Dual
Speed Motors (models Z6S/H,
Z8S/H & Z10S/H). Adjust from low
(S) to high (H) with the flick of a
switch. Manually adjust for
changes in room and static pres-
sure conditions.
Vibration Hanger
Hanger vibration eliminators feature rubber-in-shear type
and are available for use with all units.
Temperature Sensing Two Speed Switch
Yet another PennBarry Exclusive.
Designed to work with PennBarry’s
EasyTap Dual Speed Motors (models
Z6S/H, Z8S/H & Z10S/H), this switch is
optimized for areas in which tempera-
ture levels and room conditions vary. An
adjustable thermostat, mounted within
the housing, automatically switches the
fan from low (S) to high (H) speed.
Simply set the thermostat to the desired
temperature and the fan will adjust auto-
matically to meet your needs. A great
alternative to the Two Speed Switch.
Time Delay Switch AM12
The Airminder Time Delay Switch is a
UL listed, inexpensive, single gang
toggle switch and time delay relay that
operates both the fan and room light.
Airminder AM12 uses 120 volt power
and ventilates the room even after the
occupants leave. SNAP ON: Light and
fan on immediately. SNAP OFF: Light
goes off immediately. Fan is set at factory to run for 4.5 min-
utes, to clear the air after the room is left vacant. However,
time interval is field adjustable to run from 0 to 10 minutes.
The Airminder can also be used with a separate light switch
or no light at all to provide the same features as described
above. PennBarry also makes a Combination Lek-Trol™
Airminder (2 gang box required) for variable speed and time
delay.
13/32"
HOLE
DIAMETER
* Includes two (2) pieces.
7/8"
HOUSING BRACKET
(SUPPLIED W/FAN)
Z14-Z15
Z3-Z12
Duct Transition Part No. Units Round Dia.
ZT, ZJ1, Z3, Z5, Z6 56337-0 3 1/4 x 10 6
Z8, Z81, Z10 56340-0 6 x 8 8
Z12, Z101, Z102, Z121* 56385-0 6 x 8 8
11
2"
2
1
/4"
3"
PENNBARRY
