Exploded View Diagram

ManualsBrandsZephyr ManualsWine Refrigerators and Beverage CentersZephyr Presrv Stainless Steel Dual Zone Wine Cooler

1

2

Table Of Contents

26-2 52050019 Display Cover 1

26-3 56200104 Display Box 1

27 54140275 LED Light Bracket 1

28-1 50150018 Wooden Shelf w/Trim (8 Bottle) 4

28-2 50320051 Sliding Rail, Left 4

28-3 50320050 Sliding Rail, Right 4

28-4 50150017 Wooden Shelf w/Trim (7 Bottle) 1

28-5 50320052 Sliding Rail, Left (Second Shelf Upper Zone) 1

28-6 50320053 Sliding Rail, Right (Second Shelf Upper Zone) 1

29-1 50230008 Door (SN10) 1

29-1 50230016 Door (SN11+) 1

29-2 56220043 Door Gasket 1

29-3 50280006 Door Handle 1

29-4 54220010 Magnet 1

29-5 11040031 Magnet Switch 1

29-6 54140293 Door Stopper (SN11+) 1

30 50260006 Kick Panel 1

31 56130038 Water Tray 1

32 54180014 Lower Right Hinge (SN10) 1

32 54180048 Lower Right Hinge (SN11+) 1

33 54190055 Door Axis Plate (SN10) 1

33 54190067 Door Axis Plate (SN11+) 1

34 54140272 Cabinet Bracket 1

35 54180015 Lower Left Hinge (SN10) 1

35 54180049 Lower Left Hinge (SN11+) 1

36 56210087 Condensor Cover 1

37 12130037 Fan 2

38 54210023 Fan Cover 2

39 54270003 Condensor 1

40 54140273 Compressor Bracket 1

41 56210088 Decorative Hole Cover 3

42 50350006 Leveling Leg 4

01020047 Lower Hinge Screw, Hex Head, M5*10mm 2

01020048 Lower Hinge Screw, Hex Head, M5*16mm 6

AUG20.0401
