Insert Panel Dimensions:
The original stainless steel insert panel may be replaced with any 1/8” red rated piece of material. The panel
dimensions for each model are as follows;
Width Height Thickness
CSH-E48SX 42 7/8” 24 5/8” 1/8”
CSH-E42SX 36 13/16” 24 5/8” 1/8”
CSH-E36SX 31 5/16” 24 5/8” 1/8”
Removing and Installing Insert Panel:
1. Using a Phillips head screwdriver, remove (3) screws [ a] from the top cap.
2. Remove top cap [ b] and slide front insert panel [ c] up to remove from door.
3. Insert new panel the same way it was removed.
4. Replace top cap and attach with screws removed from step 1.
Remove screws [ a]
Top cap [ b]
17
Features & Controls - Door Insert Panel
FRONT PANEL [ c]
