Use, Care, and Installation Guide BML-E30BG BML-E36BG Model number: Serial Number: JUL19.
INSTALLATION Ducting Calculation Sheet........................................ Mounting Height & Clearance................................. Ducting Options............................................................ Hood Specifications.................................................... Mounting the Hood...................................................... Ductless Recirculating............................................... 5 6 7 8 9-11 12 FEATURES & CONTROLS Touch Controls..............................
Important Safety Notice READ AND SAVE THESE INSTRUCTIONS WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT USE THIS FAN WITH ANY SOLID-STATE CONTROL DEVICE. WARNING TO REDUCE THE RISK OF FIRE ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: a. Use this unit only in the manner intended by the manufacturer, if you have questions, contact the manufacturer. b.
TO REDUCE THE RISK OF FIRE, USE ONLY METAL DUCTWORK. NOT FOR USE IN OUTDOOR COOKING ENVIRONMENTS. CAUTION To reduce risk of fire and to properly exhaust air outside - Do not vent exhaust air into spaces within walls, ceilings, attics, crawl spaces or garages. OPERATION Always leave safety grilles and filters in place. Without these components, operating blowers could catch onto hair, fingers and loose clothing.
List of Materials PARTS SUPPLIED 1 - Top support frame 2 - Top duct covers Front of Hood C/ L Cut-Out Shaded Area B 1 - Paper ceiling template A 2 - Bottom duct covers 1 - Bottom support frame 1 - 6” round damper (pre-installed) 1 - Hood body w/ blower (pre-installed) 1 - Hardware package 1 - Canopy, glass 2 - 5W LED Light Strips 2 - Aluminum mesh filters HARDWARE PACKAGE CONTENTS (3) Wire Nuts (4) M6 x 1-1/2” wood screws (20) M4 x 8 pan-head machine screws (4) 3/16 x 1/4 pan-head machine screw
Duct pieces Total 1 Ft. x( ) = Ft. 6”, 7”, 8”, 10” 1 Ft. Round, straight x( ) = Ft. 3-1/ 4” x 10” Rect. 90 0 elbow 15 Ft. x( ) = Ft. 3-1/ 4” x 10” Rect. 45 0 elbow 9 Ft. x( ) = 3-1/ 4” x 10” Rect., straight Equivalent number length x used = Total 3-1/ 4” x 10” 5 Ft. Rect. to 6” round transition x( ) = Ft. 3-1/ 4” x 10” 20 Ft. Rect. to 6” round transition 90 0 elbow x( ) = Ft. 6” round to 1 Ft. 3-1/ 4” x 10” rect. transition x( ) = Ft. Ft. x( ) = Ft. 24 Ft. x( ) = Ft.
Installation – Mounting Height & Clearance Minimum mount height between range top to hood bottom should be no less than 24”. Maximum mount height should be no higher than 34”. Min. ducted 28” Min. recirc. 29” Max. 37” It is important to install the hood at the proper mounting height. Hoods mounted too low could result in heat damage and fire hazard; while hoods mounted too high will be hard to reach and will loose its performance and efficiency.
NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or garages. All exhaust must be ducted to the outside, unless using the recirculating option. Use single wall rigid Metal ductwork only. Fasten all connections with sheet metal screws and tape all joints w/ certified Silver Tape or Duct Tape.
13 3/4” ” 23 15/16” 3 1/2” Maximum - 37” 23-7/8” Min. Recirc. - 29” (top of electrical box) Min. Ducted - 28” 5/16 29 15/16”, 35 3/16” 25 9/16” FRONT SIDE 8 3/4” elec.
PAPER TEMPLATE Front of Hood C/ L Ceiling Joists B Cut-Out Shaded Area Wood Blocking 1 fron t 3 Top Support Frame A 2 FIG. B Bottom Support Frame FRONT 6 5 Hood Body/Canopy 4 FIG. C FIG. A Hood is intended to be mounted to a finished ceiling. 1. Ceiling Preparation: Determine hood mounting location and temporarily tape paper template (incluided with the hood) to the ceiling. Cut-out internal shaded area of template to allow the ductng and electrical to pass through (approx. 7”W x 7-1/2”D).
Installation – Mounting the Hood ! CAUTION: At least two installers are required due to the weight and size of the hood. BLOWER HOUSING FIG. E 1 FIG. F 5. Remove stainless steel mesh filters from hood. Place canopy over blower housing located on top of hood and secure it to hood body using (4) 3/16” x 8 screws.(FIG E) 6. Lift hood body and align the (4) pre-installed mounting screws on top of blower housing (FIG. A, #5 on Page 9) with the (4) key holes on the bottom of the support frame. (FIG.
Top Duct Covers Bottom Duct Covers Bottom Support Frame FIG. G 9. Assemble Top Duct Covers (with louver holes) together over Top Support Frame, secure Top Duct Covers together by magnetic strips. Note: If using hood in ductless recirculating mode you must install the air diverter plate to the Top Support Frame prior to assembling the duct covers. Turn to page 12 for more details. 10. Secure Top Duct Covers to Top Support Frame by using (4) 3/16 x 1/4 screws (2 screws for each Top Duct Cover). (FIG. G1).
Installation – Ductless Recirculating Ductless recirculation is intended for applications where an exhaust duct work is not possible to be installed. When converted, the hood functions as a recirculating hood rather than an exhaust hood. Fumes and exhaust from cooking are drawn and filtered by a set of optional charcoal filters. The air is then purified and re-circulated back within the home.
On/Off Lights On / Off - On/Off off button will turn power on and off for the entire hood (fan and lights). - The hood will remember the last speed and light level it was last turned off at. - Delay Off Feature: With the fan on, press and hold the On/Off button for three seconds. The fan will change to speed 1 and automatically turn off after 5 minutes. - ACT Feature: ACT allows the installer to set the maximum fan CFM to align with local codes and regulations.
Maintenance – Hood and Filter Cleaning SURFACE MAINTENANCE: Do not use corrosive detergents, abrasive detergents or oven cleaners. Do not use any product containing chlorine bleach or any product containing chloride. Do not use steel wool or abrasive scrubbing pads which will scratch and damage surface. Cleaning Stainless Steel Clean periodically with warm soapy water and clean cotton cloth or micro fiber cloth. Always rub in the direction of the stainless steel grain.
Maintenance – Lights LED LIGHT STRIPS In the unlikely event that your LED strip fails, please contact Zephyr to order replacement parts. See list of parts and accessories page for part #’s and contact information. To replace LED light strip 1. Remove aluminum mesh filters. 2. Remove light panel by two screws. 3. Disconnect LED light strip quick connector. 4. Push in the two side clips on the ends of the LED strip. 5. Push LED light strip through the light panel opening.
ACT Conversion AIRFLOW CONTROL TECHNOLOGY (ACT) Some local codes limit the maximum amount of CFM a range hood can move. ACT allows you to control the maximum blower CFM of the range hood without the need for expensive make up air kits. ACT enables the installer to easily set the maximum blower speed to one of two most commonly specified CFM levels; 390 or 290 CFM. The usage of ACT may not be necessary for your installation. Please check your local codes for CFM restrictions.
Wiring Diagrams Model:BML-E30BG BML-E36BG Voltage 120V 60Hz Power consumption Total: Max.325W @ 2.
Troubleshooting TROUBLESHOOTING PROCEDURES FOR BRISAS Issue Cause What to do After installation, the unit doesn’t work. 1. The power source is not turned ON. 1. Make sure the circuit breaker and the unit’s power is ON. 2. The power line and the cable locking connector is not connecting properly. 2. Check the power connection with the unit is connected properly. 3. The switch board and control board wirings are disconnected. 3.
PART# Replacement Parts LED Light Strip, 5W Z0B0043 Aluminum Mesh Filter 50200043 Optional Accessories Recirculating Kit BRC-0007 Replacement Charcoal Filter Z0F-C094 Duct Cover Extension (up to 12’ ceiling) B1C-00ML To order parts, call us at 1.888.880.
One Year Limited Warranty for Parts: For one year from the date of your original purchase of the Products, we will provide, free of charge, Products or parts (including LED light bulbs, if applicable) to replace those that failed due to manufacturing defects subject to the exclusions and limitations below. We may choose, in our sole discretion, to repair or replace parts before we elect to replace the Products.
