MONSOON MINI II
INSERT
CORE
Specications subject to change, check zephyronline.com for up-to-date information.
Zephyr Ventilation | 2277 Harbor Bay Parkway, Alameda, CA 94502 | 888.880.VENT
JUL21.0101
Stainless Steel
Size
Blower CFM (Min. - Max.)
Sones (Min. - Max.)
ACT 390 CFM (Min. - Max.)
ACT 290 CFM (Min. - Max.)
FEATURES
ACT™ Technology
Controls
Speed Levels
Auto Delay-O
Lighting
Dual-Level Lighting
Filters
Recirculating Option
DUCT SPECIFICATIONS
Vertical Internal Blower
Horizontal Internal Blower
AC POWER
OPTIONAL ACCESSORIES
Recirculating Kit
Make-Up Air Kit
Damper, 7” Round
MOUNTING HEIGHT RANGE**
WARRANTY
AK9528AS
30” (28-3/8”)
290 - 600
1.5 - 6
290 - 390
290 - 290
390, 290
Electronic Touch
3*
Yes
LumiLight LED, 6W x2
Yes
Hybrid Bae x2
Yes
7” Round, 3-1/4” x 10”
3-1/4” x 10”
120V, 60Hz at Max. 4A
ZRC-9100A
MUA006A
AK00067
24” - 36”
3 years parts, 1 year labor
AK9540AS
42” (40-3/8”)
290 - 600
1.5 - 6
290 - 390
290 - 290
390, 290
Electronic Touch
3*
Yes
LumiLight LED, 6W x2
Yes
Hybrid Bae x2
Yes
7” Round, 3-1/4” x 10”
3-1/4” x 10”
120V, 60Hz at Max. 4A
ZRC-9100A
MUA006A
AK00067
24” - 36”
3 years parts, 1 year labor
AK9534AS
36” (34-3/8”)
290 - 600
1.5 - 6
290 - 390
290 - 290
390, 290
Electronic Touch
3*
Yes
LumiLight LED, 6W x2
Yes
Hybrid Bae x2
Yes
7” Round, 3-1/4” x 10”
3-1/4” x 10”
120V, 60Hz at Max. 4A
ZRC-9100A
MUA006A
AK00067
24” - 36”
3 years parts, 1 year labor
AK9546AS
48” (46-3/8”)
290 - 600
1.5 - 6
290 - 390
290 - 290
390, 290
Electronic Touch
3*
Yes
LumiLight LED, 6W x2
Yes
Hybrid Bae x3
Yes
7” Round, 3-1/4” x 10”
3-1/4” x 10”
120V, 60Hz at Max. 4A
ZRC-9100A
MUA006A
AK00067
24” - 36”
3 years parts, 1 year labor
ZEPHYRONLINE.COM
MODEL
Airflow Control Technology™ (ACT™)
TM
C
is an exclusive feature built into specic Zephyr hoods which can limit the
maximum blower CFM to meet local code requirements.
*When ACT™ is enabled the maximum speed levels will change. ACT 390 = 2 speeds and ACT 290 = 1 speeds.
**Mounting height refers to distance between top of a 36” tall cooking surface and bottom of hood.
