Specifications

89
ZT400 Series
ZT400 Series General Specifications
12/10/2013 P1050133-005
ZT400 Series General Specifications
Physical Specifications
Electrical Specifications
Environmental Conditions for Operation and Storage
Dimensions
ZT410 ZT420
U.S. Standard Metric U.S. Standard Metric
Height 12.8 in 325 mm 12.8 in 325 mm
Width 10.7 in. 272 mm 13.2 in. 335 mm
Depth 19.7 in. 500 mm 19.7 in. 500 mm
Weight (without options) 36 lbs. 16 kg 40 lbs. 18 kg
Power ZT410 ZT420
General 100 to 240VAC;
47 to 63 Hz
100 to 240VAC;
47 to 63 Hz
Power Consumption
Printing
PAUSE test at slowest speed
118.7 W 220.0 W
Power Consumption
Printer idle
6.0 W 6.0 W
Fuses
5A 5A
Environment Temperature Relative Humidity
Operation Thermal Transfer 41° to 104° F
5° to 40° C
20 to 85% non-condensing
Direct Thermal 32° to 104° F
0° to 40° C
Storage Thermal Transfer or
Direct Thermal
–40° to 140° F
–40° to 60° C
5 to 85% non-condensing
