Specifications

75
ZE500 Series
ZE500 General Specifications
12/10/2013 P1050133-005
ZE500 General Specifications
Physical
Electrical Specifications
Environmental Conditions
Dimensions
ZE500-4 ZE500-6
U.S. Standard Metric U.S. Standard Metric
Height 11.8 in 300 mm 11.8 in 300 mm
Width 9.6 in. 245 mm 9.6 in. 245 mm
Depth 14.95 in. 380 mm 17.23 in. 438 mm
Weight 34 lb 15.4 kg 38 lb 17.3 kg
Power
General 100 to 240 VAC;
47 to 63 Hz
Power Consumption
Idle
Printing
20 W
375 W (maximum)
Fuses 5 Amp, 250 VAC, 5 × 20 mm IEC style, as supplied with the
printer
Environment Temperature Relative Humidity
Operation Thermal Transfer 41° to 104° F
5° to 40° C
20 to 85% non-condensing
Direct Thermal 32° to 104° F
0° to 40° C
Storage –40° to 160° F
–40° to 71° C
5 to 95% non-condensing
