Specifications

67
Z Series and RZ Series
Z Series and RZ Series General Specifications
12/10/2013 P1050133-005
Z Series and RZ Series General Specifications
Physical Specifications
Electrical Specifications
Environmental Conditions for Operation and Storage
Dimensions
ZM400/RZ400 ZM600/RZ600
U.S. Standard Metric U.S. Standard Metric
Height 13.3 in. 338 mm 13.3 in. 338 mm
Width 10.9 in. 278 mm 13.4 in. 341 mm
Depth 18.7 in. 475 mm 18.7 in. 475 mm
Weight (without options) 32.4 lbs. 15 kg 34.7 lbs. 16 kg
Power ZM400/RZ400 ZM600/RZ600
Electrical 100 to 240 VAC;
47 to 63 Hz
5 Amps (fused)
100 to 240 VAC;
47 to 63 Hz
5 Amps (fused)
Printer idle 15W 15W
Environment
ZM400/RZ400 and ZM600/RZ600
U.S. Standard Metric
Temperature Operating 41° to 104° F 5° to 40° C
Storage –40° to 140° F –40° to 60° C
Relative Humidity Operating 20% to 85%, non-condensing
Storage 5% to 85%, non-condensing
Environment Temperature Relative Humidity
Operation Thermal Transfer 41° to 104° F
5° to 40° C
20 to 85% non-condensing
Direct Thermal 32° to 104° F
0° to 40° C
Storage Thermal Transfer or
Direct Thermal
–40° to 140° F
–40° to 60° C
5 to 85% non-condensing
