PAX4 Series
170PAX4 General Specifications
48
P1050133-005 12/10/2013
170PAX4 General Specifications
Physical
Electrical Specifications
Environmental Conditions
Dimensions
170PAX4
U.S. Standard Metric
Height 11.8 in 300 mm
Width 9.6 in. 245 mm
Depth 18.3 in. 465 mm
Weight 35.5 lb 16.1 kg
Power
General 100 to 240 VAC;
47 to 63 Hz
Power Consumption
Idle
Printing
19 W
375 W (maximum)
Fuses 5 Amp, 250 VAC, 5 × 20 mm IEC style, as supplied with the
printer
Environment Temperature Relative Humidity
Operation 32° to 104° F
0° to 40° C
20 to 95% non-condensing
Storage –40° to 160° F
–40° to 71° C
5 to 95% non-condensing
