PAX4 Series
110PAX4 and R110PAX4 General Specifications
12/10/2013 P1050133-005
110PAX4 and R110PAX4 General Specifications
Physical
Electrical Specifications
Environmental Conditions
Dimensions
110PAX 4/R110PAX 4
U.S. Standard Metric
Height 11.8 in 300 mm
Width 9.6 in. 245 mm
Depth 16.4 in. 417 mm
Weight 36 lb 16.3 kg
Power
General 100 to 240 VAC;
47 to 63 Hz
Power Consumption
Idle
Printing
19 W
375 W (maximum)
Fuses 5 Amp, 250 VAC, 5 × 20 mm IEC style, as supplied with the
printer
Environment Temperature Relative Humidity
Operation Thermal Transfer 41° to 104° F
5° to 40° C
20 to 95% non-condensing
Direct Thermal 32° to 104° F
0° to 40° C
Storage –40° to 160° F
–40° to 71° C
5 to 95% non-condensing
