Specifications

HC100
HC100 Compliance Information
42
P1050133-005 12/10/2013
Mexico — NOM-121-SCT1-2009
Este equipo ha sido diseñado para operar con las antenas que enseguida se enlistan y para una
ganancia máxima de antena de [x] dB. El uso con este equipo de antenas no incluidas en esta
lista o que tengan una ganancia mayor que [x] dB quedan prohibidas. La impedancia requerida
de la antena es de [y] ohms.
This equipment has been designed to operate with the antennas that are listed below and for
maximum antenna gain of {X} dB. Using this device with antennas not included in this list or
that may have a gain higher than {X} dB is prohibited. The required antenna impedance is {Y}
ohms.
Antenna Factor — Model ANT-2.4-CW-RH-RPS
• Gain = -9.12dBi @ 2.4GHz
• Impedance = 50 ohms
WLAN Radio Specification
802.11 b
• 2.4GHz
• DSSS (DBPSK, DQPSK and CCK)
• RF power 10 mW
802.11 g
• 2.4GHz
• OFDM (16-QAM and 64-QAM with BPSK and QPSK)
• RF power 10 mW
