Specifications

15
Printer Setup
Power Cord Specifications
12/10/2013 P1050133-005
Power Cord Specifications
Depending on how your printer was ordered, a power cord may or may not be included. If one
is not included or if the one included is not suitable for your requirements, see Figure 2 and
refer to the following guidelines:
• The overall cord length must be less than 9.8 ft. (3 m).
• The cord must be rated for at least 10 A, 250 V.
• The chassis ground (earth) must be connected to ensure safety and reduce electromagnetic
interference.
Figure 2 • Power Cord Specifications
Figure 3 • International Safety Organization Certifications
Caution • For personnel and equipment safety, always use an approved three-conductor
power cord specific to the region or country intended for installation. This cord must use an
IEC 320 female connector and the appropriate region-specific, three-conductor grounded
plug configuration.
1
AC power plug for your country—This should bear
the certification mark of at least one of the known
international safety organizations (Figure 3).
2
3-conductor HAR cable or other cable approved for
your country.
3
IEC 320 connector—This should bear the
certification mark of at least one of the known
international safety organizations (Figure 3).
4
Length ≤ 9.8 ft. (3 m). Rating 10 Amp, 250 VAC.
3
1
2
4
