Installation
Install a Radio Card in a Wireless Print Server
38
P1043301-002 02/28/2012
5. Place the RF card cover over the wireless radio card, and secure it with a small screw.
6. Turn on (I) the printer.
The printer restarts and uses the wireless radio card to communicate with your WLAN.
Allow several minutes for the printer to connect to the network. For more information
about wireless status, refer to View Wireless Status through the Control Panel on page 50
or Troubleshooting the Wireless Print Server on page 135.
Note • The S4M, ZM400, ZM600, RZ400, and RZ600 printers do not use the RF card
cover.
1
Clear plastic RF card cover
(not used on all printers)
2
Screw
3
Compact Flash wireless
radio card and adapter
3
1
2
