Introduction
Printer Requirements
02/28/2012 P1043301-002
Firmware — 10/100 Print Server
The S4M printers and all external print servers are available with several versions of print
server firmware. PA X 4, 105SL, XiIIIPlus printers will use print server firmware version 1.01.x.
To determine the proper firmware version, first determine your hardware version.
To locate your hardware version, perform the following:
1. Which type of printer and print server do you have?
If you have… Then…
Any printer with an
external print server
a. Look at the side of the print server.
b. See Figure 1 on page 26. Your version is listed on the
Compliance label.
c. Your hardware version number is either blank or V2.
• If your hardware version is blank, assume this
means V1 (version 1). You will need firmware
version 1.01.x.
• If your hardware version is V2, you will need
firmware version 2.01.x.
An S4M printer with an
internal print server
a. Look at the back plate of the printer.
b. See Figure 2 on page 26. Your version is listed on the
thin Compliance label on the bracket of the wired print
server.
c. The version number is shown as blank or V2.
• If your hardware version is blank, assume this
means V1 (version 1). You will need firmware
version 1.01.x.
• If your hardware version is V2, you will need
firmware version 2.01.x.
All other printers with an
internal print server
a. Your hardware version will be V1.
b. You will need firmware version 1.01.x.
