Introduction
Printer Requirements
24
P1043301-002 02/28/2012
Memory Requirements
PCMCIA and Compact Flash Memory Cards PCMCIA memory or Compact Flash
memory cards will not work and are not supported on the Wireless Plus Print Server. The
Internal Wireless Plus Print Server and the b/g Print Server do not include a slot for these card
types.
Wireless Card Socket Option The ZebraNet wireless print server options replace the
Wireless Card Socket Option (WCSO) in 105SL printers with a serial number of 6400357 or
greater. Do not install a wireless option board on a 105SL printer with a serial number that is
less than 6400357.
Wireless Option Board A special wireless option board must be installed in your
printer/print engine. To determine if you have a wireless option board installed, use a printer
configuration label (refer to the instructions in the User Guide that came with your printer). To
purchase a wireless option, contact your authorized Zebra reseller for more information.
The wireless option boards are identified by the HARDWARE ID line on the printer
configuration label.
The part numbers shown on the HARDWARE ID line indicate the wireless print servers as
shown in Table 6.
Table 6 • Zebra Part Numbers for ZebraNet Wireless Print Server
Boards
Part Number Corresponds to the Following
P1033782-0x n Print Server
P1033557-0xx b/g Print Server
P1033605-001
29652-0xx Internal Wireless Plus Print Server
29883-001
29651-0xx Wireless Plus Print Server
29882-001
29881-009 Wireless Print Server
79077
79078
79079
79100
