Hardware Troubleshooting
Troubleshooting the Internal ZebraNet 10/100 Print Server
02/28/2012 P1043301-002
Troubleshooting the Internal ZebraNet 10/100 Print
Server
Resetting the Internal ZebraNet 10/100 Print Server to Factory
Defaults
Which model printer do you have?
Internal ZebraNet 10/100 Print Server Network Status and Activity
Indicators
For the S4M, 105SL, and PAX4 Printers/Print Engines
Alongside of the RJ45 connector, there are two LED’s containing a red element and a green
element. By turning on and off different combinations of these two LED elements, the LED
indicates Ethernet links, activity, and speed.
If you have a… Then…
ZM400 or ZM600
printer
Go to Defaulting the Print Servers on the ZM400 and ZM600
Printers on page 75.
G-Series, ZP Series, or
LP/TLP 2824 Plus
printer
Go to Defaulting the Print Servers on the ZP Series, LP/TLP
2824 Plus, and G-Series Printers on page 75.
HC100 printer Go to Defaulting the Print Servers on the HC100 Printers
on page 76.
105SL, PA X 4,
Xi4, and ZE500
printer/print engine
Go to Defaulting the Print Servers on the 105SL, PAX4, Xi4,
and ZE500 Printers on page 76.
ZT210 and ZT220
printer
Go to Defaulting the Print Servers on the ZT210 and ZT220
Printers on page 77.
ZT230 printer Go to Defaulting the Print Servers on the ZT230 Printers
on page 77.
Network Status LED State Description
Off No Ethernet link detected
Amber 10 Mbps link detected
Amber, blinking 10 Mbps link detected and Ethernet activity detected
Green 100 Mbps link detected
Green, blinking 100 Mbps link detected and Ethernet activity detected
