Control Panel
Control Panel Menu Options
126
P1043301-002 02/28/2012
Wireless Network Parameters on the LCD
Table 21 identifies the wireless network parameters available on your Zebra XiIIIPlus,
Z4Mplus/Z6Mplus, 105SL, PA X 4, Xi4, ZM400/ZM600, ZE500, and ZT230 printers/print
engines with a print server installed.
Note • The ZT210 and ZT220 printers have the same parameters available, but do not have
control panels. Refer to the Zebra ZT210/ZT220/ZT230 User Guide for more information on
how to access these parameters.
Table 21 • Wireless Network Parameters
XiIIIPlus
Z4Mplus/Z6Mplus
105SL
PAX4
Xi4, R110Xi4
ZM400/ZM600, RZ400/600
S4M
ZE500
ZT230
LCD Option Details
WIRED PS CHECK? This tells if the printer searches for
a wired print server at bootup.
PRIMARY NETWORK
The ZT230 LCD
menu will appear as:
PRIMARY PRINT
SERVER
This allows you to see if the printer
is using an IP setting from the
wireless or a wired print server at
bootup.
LOAD LAN FROM?
The Xi4 and the
ZM400/ZM600 LCD
menu will appear as:
LOAD FROM EXT?
This determines if the printer uses
IP settings from the printer or the
print server at bootup.
ACTIVE PRINTSRVR This allows you to see which print
server is being used.
IP PROTOCOL
The S4M LCD menu
will appear as:
OBTAIN IP ADDRESS
followed by:
CHANGE IP PROTOCOL
The allows you to see if the user
(permanent) or the server (dynamic)
selects the IP address.
